Performance Characteristics
1.Pulse Dust Removal System
The sweeping vehicles new pulse dust removal filter unit ensures complete gas-dust separation, converting exhaust emissions into clean air and preventing secondary pollution.
2.Italian Cartridge Valve System
The sweeping vehicles featuring an imported Italian thread cartridge valve with compact design, this system integrates electro-hydraulic proportional speed control valves to enable stepless regulation of sweeper brush rotation speeds.
3.Microcomputer-Controlled Operation
The microcontroller-based control box allows all vehicle operations to be performed from the cab, featuring simplified interfaces with minimal key switches.
4.Optimized Dust Box Design
The redesigned dust removal box and garbage bin enhance structural compactness while enabling fully automated dust removal, significantly reducing operator workload.
5.German-Assisted Engine System
Equipped with an automatic centrifugal clutch device (imported from Germany), the assistant engine ensures smooth no-load starts. Its advanced air intake filtration system guarantees optimal engine air quality and extends operational lifespan.
6.Wear-Resistant Fan Impeller
The centrifugal pumping fan impeller, treated with special anti-wear technology, enables prolonged underground operation.
7.Ergonomic & Intelligent Features
Shock-absorbing seats with vibration dampening
Air conditioning system with built-in air purification
Real-time 360° environmental monitoring
Quick-replace standardized components
Intelligent fault diagnosis for rapid issue resolution
8.Advanced Cleaning & Maintenance
Adaptive pressure regulation for brush disc adjustment on uneven surfaces
Optimized duct design for enhanced fine dust suction
Self-cleaning filtration system for sustained performance
Predictive maintenance through data analytics
Product Parameter
|
Project name |
Unit |
QTH5070TSLA |
|
Boundary dimension [L×W×H] |
mm |
5695x1955x2400 |
|
Chassis model |
HFC1070P93K1C3ZV |
|
|
Engine model |
WP3Q130E50 |
|
|
Engineer power |
kw |
96 |
|
Cab configuration |
Air conditioner |
|
|
Maximum vehicle speed |
km/h |
90 |
|
Operating speed |
km/h |
3～10 |
|
Maximum operation pressure |
MPa |
20 |
|
Sucker diameter |
mm |
200 |
|
Volume of garbage compartment |
m3 |
3.5 |
|
Max. gross mass |
kg |
7360 |
FAQ
Q1.How about your price?
Although we are brand name products,but our prices are very favorable and competitive.?Customer from all over the world to
purchase our products, because our best price.
Q2.What's your payment?
Our Payment could be
(1) 100% T/T
(2) 30% in advance, others before shipment.
(3)Advance, others letter of credit.
Q3.Could you special design and produce for you?
Sure, we have all kinds of professional engineers,
Could design and produce special product according to customer requested.
Such as: special Size, special control, or OEM, etc.
