Pipeline Unclogging Vehicle

Pipeline Unclogging Vehicle are specialized engineering vehicles designed for municipal water supply pipelines, industrial sewage pipelines, and residential rain and sewage pipelines. The vehicle is based on a second-class vehicle chassis and integrates high-pressure water jet cleaning, vacuum suction, waste transportation, and intelligent control systems. It is a multi-functional environmental sanitation equipment used for dealing with pipe blockages, sludge and scaling removal, and emergency drainage.

High-pressure cleaning: The Pipeline unclogging vehicle uses the auxiliary engine or power take-off device to provide power to the high-pressure plunger pump, raising the water pressure to 16–25 MPa (customizable to higher pressures as needed). The pressurized water flows through the high-pressure hose and the self-propelled nozzle and is sprayed out, creating strong reverse thrust inside the pipeline. This can effectively remove stubborn blockages such as grease lumps, tree roots, sand, and concrete residue, and clean the dirt adhering to the pipe wall.

Combined sewage suction system (optional for high-end models): By simultaneously starting the vacuum pump or fan system, the disintegrated sludge, sewage, and debris can be quickly sucked into the sealed tank, effectively preventing secondary pollution.

Convenient sewage discharge: The tank is made of high-strength carbon steel or stainless steel and is equipped with a hydraulic lifting and rear-opening structure, enabling the rapid and smooth discharge of waste to the designated treatment point.

High efficiency and damage-free: Using pure physical high-pressure water operation, no chemical agents are needed. It does not corrode or damage various types of pipes such as concrete, cast iron, PVC, and steel pipes.

Flexible and mobile: Blue-label models can freely enter restricted areas such as residential districts and underground garages; yellow-label large vehicles are suitable for large-scale pipeline operations on main urban roads.

Multi-functional integration: Besides pipeline cleaning and dredging, the pipeline unclogging vehicle can also be used for various purposes such as road washing, water spraying for dust suppression, and emergency fire water supply.

Environmentally friendly and compliant: The sealed tank body, combined with a leak-proof design, ensures the entire vehicle meets the National VI emission standards, effectively avoiding secondary pollution caused by spillage of contaminants.

▲Spray heads are installed on both left and right corners, making them ideal for cleaning curb edges, guardrail dividers, and sidewalks.

▲The vehicle is equipped with a spray system that disperses water to suppress dust and control air humidity.

▲The compact high-pressure cleaning vehicle features an operable water gun. When the telescopic spray pole retracts, it activates
an enhanced dual-water-flow mode for deeper cleaning, making it ideal for urban roads and squares.

Q3. How about your delivery time?
A3: Generally, it will take 30 to 60 days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.
